ORACAL® 383

Ultraleaf Cast

  • Metallised polyester film (23 micron)
  • Chrome, matt chrome, chrome-brushed and double-sided glossy gold
  • Top coated surface for printing
  • Excellent dimensional stability and good long-term ageing properties
  • For first class decorative labels, name- and technical plates, decorations and symbols
  • Solvent polyacrylate, permanent
  • Service life: 2 years (gold: 1 year)



Technical properties

Resistance

Durability 5 Year(s) with professional processing, with vertical outdoor weathering, central European normal climate
Shelf Life 2 Year(s) in original packaging, at 20 °C and 50 % relative humidity
Resistance to solvents and chemicals Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis at room temperature, 72 h after adhesion on aluminium,
Elongation at break Minimum elongation at break along: 35 %
Minimum elongation at break across: 35 %
Tensile strength Minimum tensile strength along: 17 MPa
Minimum tensile strength across: 17 MPa
EN ISO 527
Temperature resistance Minimum temperature: -54 °C
Maximum temperature: 71 °C

Adhesive properties

Adhesive power 16 N/25 mm after 24 h, on stainless steel | Average value, FINAT TM 1
Adhesive Permanent
Processing
Application temperature Minimum temperature 10 °C
Product Construction
Liner Liner: Special silicone cardboard coated on one side
Surface weight: 135 g/m²
Front material Thickness front material: 0.085 mm
Manufacturing process: Moulded
Adhesive Solvent-polyacrylate

General

Thickness 0.085 mm Average value, without protective liner and adhesive
Dimensions
Format Roll
Standard width 1220 mm
Standard length 50 m



001 Chrome

003 Gold Gloss
